Setra 370 0 TO 50 PSIA Digital Absolute Pressure Monitor, 0 to 50 psia

Setra 370 0 TO 50 PSIA Digital Absolute Pressure Monitor, 0 to 50 psia
Zoom Image
Representative image only.
Add to Compare
Setra – Mfr # 370_50A – Item # WW-98074-28
Pressure transfer standard
  • Altimeter calibration
  • Pressure switch setting
  • Min/Max tracking
  • Hi/Lo audible alarms
  • 1 year warranty
MORE +

PRODUCT OPTIONS

See All 2 Items in this Product Family

₹901,000.00INR / Each
Add To Cart
+ADD TO LIST

₹27,000.00 - ₹33,700.00INR / Each

for an additional
₹27,000.00INR / Each
for an additional
₹33,700.00INR / Each
Time to recalibrate? Click on the calibration service to view details, then order.

SPECS & DESCRIPTION

Specifications & Description

  • Accuracy±0.02% full-scale at 70°F (21°C)
  • Min Pressure (psia)0
  • Max Pressure (psia)50
  • Process Connection1/8\" NPT(F)
  • Unit Of Measurementpsi, mbar, hPa, mm Hg, \" Hg, mm WC, \" WC
  • Display6-digit LCD with annunciators for alarms, min/max, and engineering units
  • Battery Type110/220 VAC, 50/60 Hz
  • Electrical Connectionsterminal block
  • OutputRS-232
  • Media CompatibilityClean, dry air and noncondensable gases
  • DescriptionDigital Absolute Pressure Monitor, 0 to 50 psia
  • Warranty1 year
1 Year Warranty

Key Features

  • Altimeter calibration
  • Pressure switch setting
  • Min/Max tracking
  • Hi/Lo audible alarms
  • 1 year warranty

More About this Item

These barometric pressure monitors feature pressure and altitude data displayed on a 6-digit LCD; data is also accessible through a bidirectional RS-232 port. Numeric key pad provides easy access to engineering unit conversions, min/max tracking, entry of Hi/Lo alarm setpoints, nonlinear functions and calibration procedures.


Features:
0.02% full-scale accuracy
High resolution 6-digit LCD for pressure or altitude monitoring
Bidirectional RS-232 digital communications I/O port
Conversions for pressure and altitude
Digital altimeter setting indicator (DASI) and corrected altimeter mode
Programmable nonlinear functions
